TP-Link 16-Port 10/100Mbps + 2-Port Gigabit Unmanaged PoE Switch

16 PoE, 10/100Mbps RJ45, 2 Combo Gigabit SFP Slots, 2 Fans, 100-240V AC, 50/60 Hz, 7.2 Gbps

SKU
TL-SL1218MP
Brand
TP-LINK
Category
Network Switches
EAN
1210002617154
Weight
2965 kg
TP-Link 16-Port 10/100Mbps + 2-Port Gigabit Unmanaged PoE Switch

Overview

Easy to Use PoE Switch with Innovative Design
Up To 250m Data and Power Transmission for Surveillance

High PoE Power Budget
TL-SL1218MP complies with the 802.3af/at PoE+ standard, supporting up to 30W power supply on each PoE port. The total high PoE power budget of up to 192W for the 16 PoE ports, making it ideal for small to medium business surveillance systems.

Up to 250m Transmission for Surveillance
TL-SL1218MP is a special designed PoE switch for IP surveillance applications. PoE switch makes surveillance installation simpler, safer and less expensive. With the extend mode, the PoE transmission distance reaches up to 250m* which makes it perfect for IP Camera deployment in large area coverage.

Video Quality Guaranteed
Priority mode guarantees the important data, such as video surveillance, delivered with the best priority passing the data fabric even when the traffic load is heavy. Hardware switch for easy configuration with no login required.

Specifications

Management features
Switch typeUnmanaged
Ports & interfaces
Basic switching RJ-45 Ethernet ports quantity16
Basic switching RJ-45 Ethernet ports typeFast Ethernet (10/100)
Installed SFP+ modules quantity0
Combo SFP ports quantity2
Gigabit Ethernet (copper) ports quantity2
Fast Ethernet (copper) ports quantity16
Copper ethernet cabling technology10BASE-T, 100BASE-TX, 1000BASE-T
Network
Copper ethernet cabling technology10BASE-T, 100BASE-TX, 1000BASE-T
Networking standardsIEEE 802.3af, IEEE 802.3at
Flow control supportYes
Auto MDI/MDI-XYes
10G supportNo
Data transmission
Jumbo frames10000
Packet buffer memory4.1 MB
MAC address table8000 entries
Switching capacity7.2 Gbit/s
Store-and-forwardYes
Jumbo frames supportYes
Security
MAC address filteringYes
Design
Product colourBlack
StackableNo
LED indicatorsLAN, PoE, Status
Rack mountingYes
Number of fans2 fan(s)
Power
Power supply includedYes
AC input voltage100 - 240 V
AC input frequency50 - 60 Hz
Power consumption (typical)18.7 W
Power sourceAC
Power over Ethernet (PoE)
Power over Ethernet plus (PoE+) ports quantity16
Total Power over Ethernet (PoE) budget192 W
Power over Ethernet (PoE)Yes
Operational conditions
Storage temperature (T-T)-40 - 70 °C
Storage relative humidity (H-H)5 - 90%
Operating temperature (T-T)0 - 40 °C
Operating relative humidity (H-H)10 - 90%
Heat dissipation741.15 BTU/h
Weight & dimensions
Width440 mm
Depth180 mm
Height44 mm
Packaging content
Quick start guideYes
User guideYes
ManualYes
Cables includedLAN (RJ-45)
Performance
Packet buffer memory4.1 MB
StackableNo
Harmonized System (HS) code85176990
Technical details
Product colourBlack
StackableNo
Rack mountingYes
Memory
Packet buffer memory4.1 MB
Indication
LED indicatorsLAN, PoE, Status
Packaging data
Quick start guideYes
User guideYes
ManualYes
Cables includedLAN (RJ-45)
Logistics data
Harmonized System (HS) code85176990
