| Design |
|---|
| Product type | Laptop |
| Form factor | Clamshell |
| Product colour | Black |
| Display |
|---|
| HD type | WUXGA |
| Panel type | IPS |
| LED backlight | Yes |
| Display brightness | 400 cd/m² |
| Touchscreen | No |
| Display resolution | 1920 x 1200 pixels |
| Display diagonal | 35.6 cm (14") |
| Anti-glare screen | Yes |
| Maximum refresh rate | 60 Hz |
| RGB colour space | NTSC |
| Colour gamut | 45% |
| Native aspect ratio | 16:10 |
| Processor |
|---|
| Processor generation | Intel® Core™ Ultra (Series 1) |
| Processor cache type | Smart Cache |
| Processor cache | 12 MB |
| Processor model | 135U |
| Processor boost frequency | 4.4 GHz |
| Processor cores | 12 |
| Processor threads | 14 |
| Motherboard chipset | Intel SoC |
| Processor manufacturer | Intel |
| Processor family | Intel Core Ultra 5 |
| Processor base power | 15 W |
| Maximum turbo power | 57 W |
| Efficient-core base frequency | 1.1 GHz |
| Performance-core base frequency | 1.6 GHz |
| Efficient-core Max Turbo Frequency | 3.6 GHz |
| Performance-core Max Turbo Frequency | 4.4 GHz |
| Performance cores | 2 |
| Efficient cores | 8 |
| Low Power Efficient-core Base Frequency | 700 MHz |
| Low Power Efficient-core Max Turbo Frequency | 2.1 GHz |
| Low Power Efficient-cores | 2 |
| Neural processor unit (NPU) |
|---|
| Neural processor unit (NPU) | Intel AI Boost |
| Maximum frequency NPU | 1.4 GHz |
| Sparsity support | Yes |
| Windows Studio effects support | Yes |
| AI datatype support on NPU | FP16, FP32, Int8 |
| AI software frameworks supported by NPU | DirectML, ONNX RT, OpenVINO, Windows ML |
| Memory |
|---|
| Memory form factor | SO-DIMM |
| Internal memory | 16 GB |
| Memory layout (slots x size) | 2 x 8 GB |
| Internal memory type | DDR5-SDRAM |
| Memory clock speed | 5600 MHz |
| Memory slots | 2x SO-DIMM |
| Maximum internal memory | 64 GB |
| Storage |
|---|
| SSD form factor | M.2 |
| Storage media | SSD |
| Optical drive type | No |
| Number of SSDs installed | 1 |
| SSD capacity | 512 GB |
| SSD interface | PCI Express 4.0 |
| Card reader integrated | No |
| Total storage capacity | 512 GB |
| Total SSDs capacity | 512 GB |
| NVMe | Yes |
| Graphics |
|---|
| Discrete graphics card | No |
| On-board graphics card family | Intel® Graphics |
| On-board graphics card | Yes |
| On-board graphics card model | Intel® Graphics |
| Discrete graphics card model | Not available |
| On-board GPU manufacturer | Intel |
| Audio |
|---|
| Audio chip | Realtek ALC3287 |
| Number of microphones | 2 |
| Number of built-in speakers | 2 |
| Speaker power | 2 W |
| Built-in microphone | Yes |
| Camera |
|---|
| Front camera | Yes |
| Front camera resolution (numeric) | 5 MP |
| Privacy camera | Yes |
| Privacy type | Privacy shutter |
| Optical drive |
|---|
| Optical drive type | No |
| Network |
|---|
| Mobile network connection | No |
| Top Wi-Fi standard | Wi-Fi 6E (802.11ax) |
| WLAN controller model | Intel Wi-Fi 6E AX211 |
| Near Field Communication (NFC) | No |
| Wi-Fi standards | Wi-Fi 6E (802.11ax) |
| Ethernet LAN | Yes |
| Ethernet LAN data rates | 100,1000 Mbit/s |
| Bluetooth | Yes |
| Bluetooth version | 5.3 |
| WWAN | Upgradable |
| Antenna type | 2x2 |
| WLAN controller manufacturer | Intel |
| Ports & interfaces |
|---|
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 2 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity | 0 |
| USB Sleep-and-Charge | Yes |
| USB 2.0 ports quantity | 0 |
| HDMI ports quantity | 1 |
| HDMI version | 2.1 |
| Ethernet LAN (RJ-45) ports | 1 |
| Combo headphone/mic port | Yes |
| USB Power Delivery (USB PD) | Yes |
| Thunderbolt 4 ports quantity | 2 |
| Intel® Thunderbolt 4 | Yes |
| Performance |
|---|
| Motherboard chipset | Intel SoC |
| Keyboard |
|---|
| Pointing device | ThinkPad UltraNav |
| Numeric keypad | No |
| Keyboard backlit | Yes |
| Keyboard language | English |
| Software |
|---|
| Operating system language | English |
| Bundled software | Intel Connectivity Performance Suite |
| Operating system installed | Windows 11 Pro |
| Technical details |
|---|
| Form factor | Clamshell |
| Product colour | Black |
| Battery |
|---|
| Battery capacity | 52.5 Wh |
| Power |
|---|
| AC adapter power | 65 W |
| USB Power Delivery (USB PD) | Yes |
| USB Type-C charging port | Yes |
| Security |
|---|
| Cable lock slot type | Kensington |
| Trusted Platform Module (TPM) | Yes |
| Cable lock slot | Yes |
| Smart card reader | No |
| Trusted Platform Module (TPM) version | 2.0 |
| Certificates |
|---|
| Certification | ENERGY STAR,TCO,EPEAT Gold,RoHS |
| Weight & dimensions |
|---|
| Width | 315.9 mm |
| Depth | 223.7 mm |
| Height | 17.7 mm |
| Weight | 1.38 kg |
| Packaging data |
|---|
| AC adapter included | Yes |
| Packaging content |
|---|
| AC adapter included | Yes |
| Other features |
|---|
| WLAN controller model | Intel Wi-Fi 6E AX211 |
| On-board graphics card | Yes |
| AC adapter included | Yes |
| Anti-glare screen | Yes |
